Angle Seat Valve with Electro-Pneumatic Positioner
Angle Seat Valve with Electro-Pneumatic Positioner -1162, 1163, Series
The Angle Seat Valve with Electro-Pneumatic Positioner is a compact, efficient, and cost-effective solution for medium-accuracy flow regulation. Combining the high-flow, water-hammer-free performance of the angle seat design with a precision electro-pneumatic positioner, it enables proportional control via a standard 4–20 mA input signal.
Ideal for applications where moderate control accuracy, fast switching, and reliability matter more than ultra-precise throttling, this valve is perfect for industries with space constraints and continuous duty operations.
Applications: Paint batching, HVAC modulation, poultry processing, autoclave systems, industrial washing, blending systems, chemical dosing, and general-purpose flow regulation.
Technical Specifications
Parameter
Sizes
15mm to 100mm (1162 series), 15mm to 50mm (1163 series)
End connection
BSP Screwed / Socket or Butt weld / Flanged end / Tri clamp end
Body Material
Bronze / Stainless Steel (SS304 / SS316 / SS316L)
Sealing Material
PTFE or R-PTFE or PPL or VITON
Medium
Coolant / Air / Water / Steam / Nitrogen / Vacuum / Chemicals etc
Pressure Range
0 – 16 bar (customizable up to 25 bar)
Medium Temperature
–10°C to +180°C [Standard] / Upto +220°C for PPL Seat
Ambient Temperature
–10°C to +60°C (PA actuator) / +5°C to +130°C (PPS actuator)
Actuator Material
PA (Polyamide) / Optional SS304
Design & Construction:
Combining the high-flow, water-hammer-free performance of the angle seat design with a precision electro-pneumatic positioner, it enables proportional control via a standard 4–20 mA input signal. Designed for compact installations and continuous duty applications where space efficiency and reliable modulation are required.
Working Principle:
Working Principle
The electro-pneumatic positioner receives a 4–20 mA control signal and regulates air pressure to the actuator, positioning the valve proportionally to control the required flow.
Automation & Control Options:
- Input Signal: 4–20 mA
- Output Signal: 4–20 mA
- Control Type: Modulating / Proportional
- Feedback: Internal position sensor
- It can be supplied with MODBUS/PROFIBUS for more control duty application
Key Features & Advantages
- Compact, efficient, and cost-effective solution for medium-accuracy flow regulation. Enables proportional control via a standard 4–20 mA input signal and combines angle seat valve performance with electro-pneumatic positioning for controlled flow applicat
Optional Accessories:
- Position Feedback Switch / Limit switch indicator
- Proximity sensor
- Electro-Pneumatic Positioner
- NAMUR Pilot Solenoid Valve
- Adjustable Stroke Limiting Screws
- PID Controller with PT-100 Sensor
- Manual Override
- FDA-Grade Sealing Materials (Ra value of 0.6µm or better)
Industries Served
Paint batching
HVAC modulation
Poultry processing
Autoclave systems
Typical Applications:
Angle Seat Valves with Electro-Pneumatic Positioner are designed for precise proportional flow control, allowing accurate regulation of liquid flow based on real-time system requirements. These valves are ideal for applications where continuous modulation, high accuracy, and stable control performance are critical, ensuring consistent process output and efficiency.
