Snort Valve
Snort Valve – Series 1930
The Snort Valve – Series 1930 from SUDE Engineering Private Limited is a high-performance butterfly-type damper valve designed for installation in the cold-blast line of blast furnace systems. Its primary function is to rapidly vent excess air to the atmosphere without interrupting blower operation, maintaining pressure balance and preventing gas backflow, thereby ensuring smooth and safe furnace operation.
Engineered for extreme industrial conditions, the Snort Valve provides reliable performance during pressure surges, stove switchover, or maintenance operations. Its robust butterfly design and precision-sealing mechanism deliver consistent operation, minimizing the risk of mechanical failure and ensuring system integrity.
Constructed from high-strength, heat-resistant materials, the valve withstands the thermal and mechanical stresses typical of steel plant environments. It ensures fast actuation and dependable airflow control, protecting downstream equipment and maintaining operational efficiency during critical blast furnace processes.
The valve supports manual, pneumatic, or electric actuation, allowing seamless integration into automated plant control systems. Widely used in steel plants, ironmaking facilities, and heavy industrial processes, the Snort Valve reflects SUDE Engineering Private Limited’s commitment to high-performance engineering, safety, and reliable industrial solutions.
Technical Specifications
Parameter
Valve Type
Butterfly valve with integrated blow-off (“snort”) system
Shapes Available
Circular configuration
Size Range
DN 300 – 2000 mm (custom sizes available)
Flow Media
Cold blast air
Blade Type
Single disc butterfly arrangement
Sealing Efficiency
Designed for pressure-tight performance in cold-blast applications
Sealing Type
Metal-to-metal or resilient sealing
Temperature Range
Up to 200 – 400 °C
Material of Construction
Mild Steel / Carbon Steel / Alloy Steel
Pressure Rating
Up to 0.4 – 0.5 MPa
Drive Operation
Manual lever, electric, pneumatic, or hydraulic actuator
Silencer
Integrated muffler to maintain noise levels below 85 dB
Installation Orientation
Horizontal or vertical mounting on cold-blast main
Design Standards
Blast furnace and metallurgical air system standards
Testing Standards
Leak, pressure, and functional performance testing
Working Principle:
Normal Operation
The butterfly disc remains open, allowing the blower to supply cold air to the furnace and stove.
Rapid Pressure Relief Mode
During high-pressure conditions or maintenance, the valve opens fully to vent excess air through the blow-off line to the atmosphere.
Positive Pressure Maintenance
Maintains slight positive pressure in the blast line, preventing furnace gas from backflowing into the blower.
Noise Suppression
Integrated silencer reduces discharge noise levels to below 85 dB, ensuring safe operation in plant environments.
Key Features & Advantages
- Enables rapid pressure relief without affecting blower operation
- Prevents reverse gas flow into blowers and ducting
- Integrated noise suppression for safe operation
- Rugged construction for metallurgical and high-duty service
- Supports automated control and fail-safe actuation options
Why Choose ?
- Proven performance in iron and steel plant cold-blast systems
- Custom-built to handle pressure, temperature, and flow variations
- Designed for long service life with minimal maintenance
- Field-proven integration with plant automation systems
- Backed by Sude’s engineering, fabrication, and testing expertise
SUDE Snort Valve Advantage:
It enables rapid pressure relief without disrupting blower operation and prevents reverse gas flow into blowers and ducting for enhanced system safety.
The rugged construction suits metallurgical and high-duty applications, featuring integrated noise suppression along with support for automated control and fail-safe actuation options.
Applications
Blast furnace cold-blast main systems
Pressure regulation during stove switchover or shutdown
Emergency venting without blower stoppage
Industrial blower protection systems
