Electric Operated 2-Way & 3-Way Globe Control Valves
Electric Operated 2-Way & 3-Way Globe Control Valves -1752, 1753 Series
SUDE Engineering Pvt. Ltd. presents its advanced Electric Operated 2-Way & 3-Way Globe Control Valves from the renowned 1752 / 1753 Series, designed using next-generation engineering, state-of-the-art manufacturing technology, and stringent quality processes.
These valves are built for accurate throttling, reliable shut-off, and stable modulating control, making them ideal for a wide spectrum of industries including process, power, oil & gas, chemical, food, pharmaceutical, HVAC, and general utilities.
Each valve integrates a precisely engineered body, bonnet, and SDTORK Electric Actuator, delivering smooth, intelligent, and highly responsive flow management based on electrical signals.
The result is consistent performance, energy efficiency, and long service life in demanding operating environments.
Technical Specifications
Parameter
Series
1752 / 1753
Description
Electrically Operated 2-Way & 3-Way Globe Control Valve
Valve Sizes
½” to 16” (15–400 mm)
End Connections
ANSI / DIN / BS: Flanged RF, FF, RTJ, Butt-Weld, Socket Weld, Screwed
Body Ratings
ANSI 150–2500 (PN20–PN420), DIN/BS 4504 PN10–PN400
Design Standard
ANSI B 16.34
Trim Designs
Contoured (Full/Reduced), Microspline, Ported Cage, HF, HFD, HFT
Plug Options
Unbalanced (Metal/Resilient), Balanced (Metallic/Resilient Seal Rings)
Flow Characteristics
Equal Percentage, Linear, Quick-Open
Material Options
Multiple body, bonnet & trim selections based on fluid/media
Bonnet Types
Standard, Normalizing, Bellows Seal, Cryogenic
Actuator
SDTORK Electric Actuator – Single Phase / Three Phase
Valve Type
2-Way (NC/NO), 3-Way (Mixing / Diverting)
Optional Accessories
Potentiometer, Position Transmitter, Controller, Integral Starter, LCP, Thermostat, Space Heater, MODBUS RS485
Working Principle:
Open Position
Actuator lifts the plug → maximum flow
Modulating Position
Plug moves precisely based on electrical input → accurate throttling
Closed Position
Plug seats fully → tight, reliable shut-off
Automation & Control Options:
- Control Modes: On/Off, Modulating (4–20 mA / 0–10 V)
- Control Modes: On/Off, Modulating (4–20 mA / 0–10 V)
- Actuator Options: Single Phase, Three Phase, IP67 / IP68, Flameproof (optional)
- Feedback Systems: Limit Switches, Position Transmitter, Potentiometer
- Communication: PLC / DCS Integration (4–20 mA, 0–10 V signals)
- Control Interface: Local Control Panel (LCP), Remote Operation, Integral Starter
Optional Accessories:
- Positioner
- Position Transmitter
- Digital/Analog Controllers
- Local Control Panel
- Thermostat
- Space Heater
- MODBUS RS485 communication
Industries Served
Textile Processing
Paper & Pulp
Power Generation
Chemical & Petrochemical
General Process Industries
