Electric Operated Metal Ball Valves
Electric Operated Metal Ball Valves -1352, 1353, 1355 Series
SUDE Electric Operated Ball Valves are high-performance, quarter-turn rotary valves engineered for reliable shut-off, precise flow control, mixing, and diverting applications across a wide range of industries. These valves feature precision-machined floating or trunnion-mounted balls combined with robust electric actuators, ensuring bubble-tight sealing, smooth operation, low torque, and long service life.
The range includes Electric Operated 2-Way and 3-Way Ball Valves, Compact & Sleek Motorized Ball Valves, Electrically Operated Butt-Weld, I-Line, and Sanitary Clamp Metallic Ball Valves. Designed for automation-ready integration, SUDE valves outperform conventional gate, globe, or solenoid valves in continuous-duty, high-cycle, and harsh operating environments.
Built with Carbon Steel, SS304, SS316/SS316L, and equipped with advanced PTFE or reinforced soft seats, these valves offer versatility, reliability, and low maintenance across industrial automation, process control, water, oil, gas, steam, chemical, and hygienic applications.
Technical Specifications
Parameter
Electric Operated 2
Way Ball Valves (Full / Reduced Bore – 1352 Series)
Electric Operated 3
Way Ball Valves – Mixing & Diverting (1353 Series)
Compact & Sleek Motorized Ball Valves
Solenoid Valve Replacement (1355 Series)
Electrically Operated Butt-Weld Metallic Ball Valves
Zero Bacteria (1357 Series)
Electrically Operated I-Line Metallic Ball Valves
Zero Leakage, One-Piece Body
Electrically Operated Sanitary Clamp Ball Valves
Hygienic & CIP/SIP Compatible (1367 Series)
Material Options
Carbon Steel, SS304, SS316, SS316L, Brass
End Connections
BSP, NPT, Flanged, Socket Weld, Butt Weld, I-Line, Sanitary Clamp
Electric Actuators
Single Phase / Three Phase, Multiple Voltage Options
Design & Construction:
Precision-machined floating or trunnion-mounted balls combined with robust electric actuators ensure bubble-tight sealing, smooth operation, low torque, and long service life. Designed for automation-ready integration and continuous-duty industrial environments.
Working Principle:
Open Position:
The ball bore aligns with the pipeline, allowing unrestricted flow.
Closed Position: The ball rotates perpendicular to the flow path, completely blocking the media and ensuring tight shut-off.
Closed Position: The ball rotates perpendicular to the flow path, completely blocking the media and ensuring tight shut-off.
3-Way Operation:
L-Port or T-Port ball enables mixing or diverting flow between multiple pipelines.
Modulating Control (Optional):
Positioner-controlled actuator allows throttling up to 60° for flow regulation.
Automation & Control Options:
- Control Modes: On/Off, Modulating (4–20 mA / 0–10 V), Inching
- Actuator Options: Single Phase / Three Phase, Multi-voltage
- Feedback Systems: Limit Switch, Position Transmitter, Potentiometer
- Communication: MODBUS (RS-485), PLC / SCADA Compatible
- Control Interface: Local Control Panel, Remote Operation, Integral Starter
Key Features & Advantages
- Bubble-Tight Shut-Off – Precision-machined ball and advanced PTFE seating ensure zero leakage.
- Quick Quarter-Turn Operation – Only 90° rotation for fast and reliable opening and closing.
- High Flow Efficiency – Full-bore design minimizes pressure drop and energy loss.
- Automation Ready Design – ISO mounting pad allows easy actuator integration without body modification.
- Rugged & Durable Construction – Available in metallic and plastic materials for harsh and corrosive environments.
- Low Maintenance & Long Life – Wear-resistant seats and hardened ball surfaces ensure extended service life.
- Superior Alternative to Solenoid Valves – Suitable for high temperature, dirty media, vacuum, and continuous ON conditions.
Optional Accessories:
- Limit Switch Box
- Position Transmitter
- Potentiometer
- Integral Starter
- Thermostat & Space Heater
- Manual Override
- Local Control Panel
Industries Served
Food & Beverage Processing
Pharmaceutical & Bio-Pharma
HVAC & Building Automation
Pulp & Paper
Typical Applications:
Industrial automation, process control, water, oil, gas, steam, chemical, and hygienic applications requiring reliable shut-off, mixing, or diverting flow control.
